Nanjing Jinhui cia khoom Co., Ltd. Txais tos rau cov lag luam wholesale zoo cia khoom ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Peb kuj txais customized txiav txim.

Product Overview

CovTsav Hauv Cia Racking Systemyog ib qho siab -cov khoom ntim ntim cov khoom ntim khoom tsim los khaws cov khoom loj ntawm homogeneous palletized. Nws yog dav siv nyob rau hauv txias cia warehouses, zaub mov & dej haus, manufacturing, thiab logistics chaw.

Los ntawm kev tso cai rau forklifts tsav ncaj qha mus rau hauv txoj kab racking, lub kaw lus txo qhov chaw ntawm txoj kab thiab ua tiav txog li 80% qhov chaw siv, ua rau nws zoo tagnrho rau cov tsev khaws khoom uas muaj qhov chaw tsawg thiab xav tau siab cia.

industrial drive in racking system for warehouse storage

Ntsiab nta & qhov zoo

High -Density Storage

Tshem tawm ntau txoj kab ke thiab tso cai rau txoj kab sib sib zog nqus, ua kom muaj peev xwm ntawm cov khoom lag luam.

Tus nqi -Kev daws teeb meem zoo

Txo cov kev xav tau ntawm lub tsev thiab txhim kho kev khaws cia, txo cov nqi ua haujlwm tag nrho.

Zoo tagnrho rau Bulk Storage

Qhov zoo tshaj plaws rau khaws cia ntau yam ntawm cov khoom zoo sib xws nrog tsawg SKU ntau yam.

LIFO Storage System

Ua haujlwm ntawm qhov kawg-Nyob rau hauv, Ua ntej-Tawm (LIFO) hauv paus, haum rau cov khoom uas tsis yog -perishable los yog batch- tswj cov khoom muag.

Txias Cia Compatible

Tsim los ua kom muaj kev ntseeg siab nyob rau hauv qis - qhov kub thiab txias ib puag ncig xws li cov chav txias thiab cov tub yees warehouses.

Customizable Tsim

Muaj nyob rau hauvtsav -inthiabtsav-los ntawm kev teeb tsa, haum rau koj lub tsev khaws khoom layout thiab kev ua haujlwm xav tau.

Cov ntsiab lus tseem ceeb

Yam khoom	Specification
Khoom npe	Tsav Hauv Cia Racking System
Hom	JINHUI
Qauv	JH-DIR
Khoom siv	Q235B steel hlau
Load Capacity	300-1500 kg ib pallet
Rack Qhov siab	Txog li 13,000 mm
Khib dav	800-1200 hli
Hlau Thickness	1.5-3.0 hli
Kev kho saum npoo	Hmoov Coated / Galvanized
Xim	RAL System (Xiav / Txiv kab ntxwv / Customized)
Qauv	Bolt- txuas, yooj yim los ua ke
Daim ntawv thov	Warehouse, Txias Cia, Industrial Cia
Chaw nres nkoj	Nanjing / Shanghai

Cov Qauv Txheej Txheem

Lub system yog tsim los ntawm:

Upright Ncej
Load Rails
Sab saum toj Beams
Txhawb nqa caj npab
Kab Spacers
Guide Rails (rau forklift alignment)

Tag nrho cov khoom yog tsim los rau kev ruaj ntseg siab, ua haujlwm ntev, thiab kev nyab xeeb hauv kev ua haujlwm hnyav -.

drive in racking system structure components

Txoj Cai Ua Haujlwm

Pallets yog khaws cia rau ntawm txoj kev txhawb nqa hauv txoj kab sib sib zog nqus. Forklifts nkag mus rau hauv racking system kom thauj khoom thiab khaws cov khoom.

Txoj kev khaws cia:LIFO (Kawg-Nyob rau hauv, Thawj-Tawm)
Forklift Kev Ua Haujlwm: Tsav- nkag mus
Zoo tagnrho rau: High-density, low-rotation inventory

Daim ntawv thov

Qhov no system yog dav siv nyob rau hauv:

Txias Cia Warehouses
Khoom noj khoom haus & dej haus kev lag luam
Tshuaj Cia
Kev tsim cov nroj tsuag
Logistics & Distribution Centers

Yuav Qhia Li Cas Yog Tsav Tsheb -hauv Racking System yog txoj cai rau koj

Ua ntej cog lus rau lub tsav tsheb -hauv pallet khib system, ntau yam tseem ceeb rau kev txiav txim siab.

Ua ntej, nws yog ib qho tseem ceeb kom paub tseeb tias koj cov khoom puas haum nrog Qhov Kawg -Nyob rau hauv, Ua ntej -Tawm (LIFO) txoj kev khaws cia thiab yog tias koj qhov kev ua haujlwm yuav tsum tau xaiv tsawg kawg nkaus. Cov khoom lag luam nrog lub sijhawm txwv, cov khoom tsis zoo, thiab cov khoom me me yuav tsis haum rau qhov system no. Tsis tas li ntawd, qhov sib npaug ntawm pallet sizing thiab thauj khoom- cov kabmob muaj peev xwm yog qhov tseem ceeb, nrog rau kev ua raws li cov txheej txheem ua haujlwm los tiv thaiv kev sib tsoo honeycombing.

Tsis tas li ntawd, tus nqi ntawm qhov system yuav tsum tau ua tib zoo soj ntsuam. Tsav- nyob rau hauv racks feem ntau yuav raug nqi ntau dua piv rau lwm lub chaw cia khoom. Yog li ntawd, nws yog ib qho tseem ceeb rau kev ntsuam xyuas seb qhov kev cia siab ntau ntxiv uas muab los ntawm qhov system no ua rau kev nqis peev.

Packing & Delivery

warehouse racking export packaging and shipment

Hais txog JINHUI

Founded hauv 2006, JINHUI yog ib lub chaw tsim khoom tshwj xeeb hauv cov chaw cia khoom, suav nrog:

Pallet Racking Systems

Mezzanine Floors
Cantilever Racking
Shuttle Racking Systems
Industrial Shelving

Nrog ib20,000㎡ chaw tsim khoom, cov cuab yeej siv siab heev, thiab kev tswj xyuas nruj, peb muab cov kev daws teeb meem txhim khu kev qha thiab kho kom haum rau cov neeg siv khoom thoob ntiaj teb. Peb cov khoom raug xa tawm mus dhau50 lub teb chaws thoob ntiaj teb.

our certificate

Peb tau txais cov lus pom zoo thiab kev lees paub los ntawm cov neeg siv khoom thoob ntiaj teb rau peb cov khoom zoo thiab kev pabcuam txhim khu kev qha.

customer reviews
